System Operations 5-4 Preset Menu
Cell Master UG PN: 10580-00250 Rev. K 5-7
5-4 Preset Menu
Key Sequence: Shift, Preset (1)
5-5 Self Test
At power on, the Cell Master runs through a series of quick checks to ensure that the system
is functioning properly. The System self test runs a series of tests that are related to the
instrument. The Application Self Test runs a series of tests that are related to the current
operating mode of the instrument.
If the Cell Master is within the specified operating range with a charged battery, and the self
test fails, then contact your Anritsu Service Center (http://www.anritsu.com/Contact.asp).
To start a self test when the system is already powered up:
1. Press the Shift key and then the System (8) key.
2. Press the Self Test submenu key. The Self Test results are displayed.
3. Press Esc to continue.
Preset: This key resets the instrument to the default starting conditions.
Save Setup: Opens the Save dialog box (Figure 4-1) to name and save the
current operating settings, allowing them to be recalled later to return the
instrument to the state it was in at the time the setup was saved.
The saved setup can be named using the touch screen keyboard. Use the
Caps key to select an upper case letter. Use the Left/Right directional
arrows to move the cursor position. Press Enter to save the setup.
Note: Set the File type as Setup. See “Save Menu” on page 4-9 for details.
Recall Setup: This key allows the selection and recall of a previously stored
instrument setup using the “Recall Menu” on page 4-12. Use the rotary knob,
the Up/Down arrow keys, or the touchscreen to highlight the saved setup,
and press Enter. All current instrument settings are replaced by the stored
setup information.
Figure 5-7. Preset Menu
Recall
Setup
Preset
Save
Setup
Preset
