10580-00176 55
has completed.
9 512 Not implemented
10 1024 Not implemented
11 2048 Not implemented
12 4096 Not implemented
13 8192 Not implemented
14 16384 Not implemented
15 0 Will always be 0
SYSTem Subsystem
This subsystem contains commands that affect instrument functionality that does not
directly relate to data collection, display or transfer.
Query Installed Options
:SYSTem:OPTions?
Returns a string of the installed options. Options will be separated by a “/”.
The string will return “NONE” if no options are installed.
See Also:
*IDN?
Preset
:SYSTem:PRESet
This command restores all application parameters to their factory preset values. This
does not modify system parameters such as Ethernet configuration, language, volume or
brightness.
Front Panel Access:
Shift-1 (Preset), Preset
See Also:
*RST
Trace Subsystem
This subsystem contains commands related to the transfer of trace data to and from the
instrument.
Trace Data Transfer
:TRACe[:DATA] ACLR|SPECtrum|EMISsion|DEMod,
(<header><block>)
:TRACe[:DATA]? ACLR|SPECtrum|EMISsion|DEMod
This command transfers data from the controlling program to the instrument. The query
form transfers trace data from the instrument to the controller.
The ASCII header specifies the number of data bytes. It looks like #AX, where A is the
number of digits in X and X is the number of bytes in the <block>. The number of
bytes in the block is calculated by multiplying the number of data points by the number
