Read Occupied Bandwidth
:READ:OBWidth?
Triggers a new occupied bandwidth measurement and returns the results: occupied
bandwidth, percent of power and dB down. It is a combination of the commands
:ABORT;:INITiate;:FETCh:OBWidth?
The occupied bandwidth measurement must be the active measurement (specified by
:CONFigure:OBWidth). The current measurement can be queried using
:CONFigure?
Data is returned as 3 comma-separated values: occupied bandwidth, percent of power, dB
down.
Default Units: For OBW: Hz
For Percent of Power: %
For dB Down: dB
See Also:
:CONFigure
Read Tracking Generator Absolute Statistics
:READ:TGENerator:ABSStats?
Triggers a new tracking generator absolute statistic measurement and returns the results.
It is a combination of the commands
:ABORT;:INITiate;:FETCh:TGENerator:ABSStats?
The tracking generator absolute statistic measurement must be the active measurement
(specified by :CONFigure:TGENerator ABSStats). The current measurement
can be queried using :CONFigure?
Data is returned as 3 comma-separated values: absolute max power, absolute min power,
absolute average power.
Required Options: 20
Read Tracking Generator Relative Statistics
:READ:TGENerator:RELStats?
Triggers a new tracking generator relative statistics measurement and returns the results.
It is a combination of the commands
:ABORT;:INITiate;:FETCh:TGENerator:RELStats?
The tracking generator S21 Insertion Loss relative statistic measurement must be the
active measurement (specified by :CONFigure:TGENerator RELStats). The
current measurement can be queried using :CONFigure?
Data is returned as 3 comma-separated values: relative max power, relative min power,
relative average power.
Required Options: 20
