Anritsu Spectrum Master MS2721B Programming Manual

10580-00176 76
Factory Preset / *RST:
OFF
Front Panel Access:
Shift-4 (Measure), Tracking Generator, S21 Insertion
Loss, S21 Max,Min,Avg (On/Off)
Required Option: 20
See Also:
INITiate:TGENerator
[:SENSe]:TGENerator:S21:NORMalize[:STATe]
Tracking Generator Scale
[:SENSe]:TGENerator:S21[:SCALe]:PDIVision <rel ampl>
[:SENSe]:TGENerator:S21[:SCALe]:PDIVision?
Sets the tracking generator scale (dB/division).
Factory Preset /
*RST:
10 dB/div
Range: 1 dB to 15 dB
Default Unit: dB
Front Panel Access:
Shift-4(Measure), Tracking Generator, S21 Insertion
Loss,S21 Scale.
Required Options: 20
See Also:
:INITiate:TGENerator
Tracking Generator Reference Level
[:SENSe]:TGENerator:S21[:SCALe]:RLEVel <amplitude>
[:SENSe]:TGENerator:S21[:SCALe]:RLEVel?
Sets the tracking generator reference level amplitude value for the y-axis.
Factory Preset /
*RST:
0 dB
Range: With reference level offset = 0 dB:
-200 dB to 20 dB
Default Unit: Current active amplitude unit
Front Panel Access:
Shift-4(Measure),Tracking Generator,S21 Insertion Loss,
S21 Ref Level
Required Options: 20
See Also:
[:SENSe]:TGENerator:S21[:SCALe]:RLEVel:OFFSet
<rel ampl>
:UNIT:POWer
Tracking Generator Reference Level Offset
[:SENSe]:TGENerator:S21[:SCALe]:RLEVel:OFFSet <rel ampl>
[:SENSe]:TGENerator:S21[:SCALe]:RLEVel:OFFSet?
Sets the tracking generator reference level offset value for the y-axis.
