LUME20 - MANUAL
19 | LUME20 – Manual | AntecControls.com
Alarm Active
Display Component
Description
1
Room Name
The current name of the room is displayed. This is
configurable through the Monitored Room menu.
2
Settings Button
Allows access to settings. This is password
protected.
3
Room Status
Displays Alarm to indicate there is an alarm active.
4
Alarm Reason
Displays the type of alarm that is active. Options:
1. Door Open
2. Low Pressure
3. High Pressure
4. Binary Input (Configurable display message,
see Binary Inputs)
5
Room Mode
Allows the user to override the room mode. This is
password protected. Default Password: 1-2-3-4.
NOTE: Any overrides done locally through the
touchscreen will follow mode priority.
