LUME20 - MANUAL
18 | LUME20Manual | AntecControls.com
Caution Active
Display Component
Description
1
Room Name
The current name of the room is displayed. This is
configurable through the Monitored Rooms menu.
2
Settings Button
Allows access to settings. This is password
protected.
3
Room Status
Displays Caution to indicate there is a caution active.
4
Caution Reason
Displays the type of caution that is active. Options:
1.
Door Open
2.
Low Pressure
3.
High Pressure
4.
Binary Input (Configurable display message,
see Binary Inputs)
5
Room Mode
Allows the user to override the room mode. This is
password protected. Default Password: 1-2-3-4.
NOTE: Any overrides done locally through the
touchscreen will follow mode priority.
