R7
- OPERATING INSTRUCTION
5.2. Foot control
1
"Power Pedal" foot control.
NOTE: the "multifunction" and "pressure" foot controls can also be
supplied in wireless version.
1
2
3
4
5
6
7
Joystick for dental chair movement (3).
With instrument removed
NOTE: At the end of work, air is automatically blown to eliminate
any drops of liquid remaining in the spray ducts.
With instruments in place
NOTE: If the pedal is pushed fully left again, the dental chair moves
back to the work position.
WARNING!
These dental chair functions are activated by keeping the pedal at the
end of the travel for at least 2 seconds.
Controller joystick for dental chair movement ( 3 )
NOTE: all the buttons used to move the dental chair are inoperative
when an instrument is removed and the foot control pedal is actuated.
NOTE: the joystick operating mode can be changed with the instru-
ment removed (see Paragraph 5.1.1.2.3.).
