EN
R7
- OPERATING INSTRUCTION
5. Instrument board operation
Layout of instruments.
Starting the instruments.
Simultaneous use of the instruments.
Putting the instrument board place.
a
NOTE (only for pantograph arm with pneumatic brake): to
adjust the height of the dentist’s instrument board, you rst need to press
the brake release button .
NOTE model R7 CART / R7 M CART: o adjust the height of
the dentist’s instrument board, you rst need to press the brake release
button .
Pantograph arm.
Adjusting the pantograph arm with manual brake.
b
Instrument return arm stopping device (only for CONTINENTAL ver-
sion instrument boards).
B
Tray holder module for CONTINENTAL version dentist’s instrument board.
f
WARNING!
Maximum permitted load on the tray holder module ( f ): 2 kg distri-
buted.
Tray holder module for INTERNATIONAL version dentist’s instrument board.
e
WARNING!
Maximum permitted load on the tray holder module ( e ): 2 kg distri-
buted.
