R7
- OPERATING INSTRUCTION
Description of the parts
1
2
3
4
5
6
7
Control pedal ( 2 )
a
NOTE: the control pedal adjusts the speed/power of the instrument
from the minimum to the maximum value set from the instrument board.
a
NOTE: with the spray active, at the end of the operation a blast
of air is automatically activated to remove any residual drops of liquid in
the spray ducts.
WARNING!
Instrument spray is activated and deactivated by pressing the but-
tons ( 4 ) or ( 5 ).
A beep sounds to signal the operating status has been changed.
When the LED ( 6 ) is on, it indicates operation with spray.
Left-hand button operation ( 4 ).
• Key held down (at least 2 seconds) with the instrument removed:
NOTE: Press the key again to bring the chair back to the work
position.
Right-hand button operation ( 5 )
• Key held down (at least 2 seconds) with the instrument removed:
• Key held down (at least 2 seconds) with the instruments in place:
WIRLESS version.
Protection against liquid penetration.
Cleaning.
NOTE: If the foot control slips on the oor, dust the slip-proof rubber found under the base with a dry cloth.
