35
35EN
R7
- OPERATING INSTRUCTION
Joystick for dental chair movement (3).
NOTE: All the buttons used to move the dental chair are inoperative
when an instrument is removed and the foot control pedal is actuated.
NOTE: the joystick operating mode can be changed with the instru-
ment removed (see Paragraph 5.1.1.2.3.).
Left-hand button operation ( 4 ).
•
NOTE: Pressing the button a second time returns the dental chair
into working position.
•
NOTE: The control works only when the turbine and micromotor
are in working position.
•
WARNING!
A short acoustic signal warns of the switch.
When the LED ( 6 ) is on, it indicates operation with spray.
Right-hand button operation ( 5 ).
•
•
4
•
WARNING!
A short acoustic signal warns of the switch.
When the LED ( 6 ) is on, it indicates operation with spray.
Wireless version.
Protection against liquid penetration.
Cleaning.
NOTE: if the foot control slips on the oor, dust the slip-proof rubber found under the base with a dry cloth. .
