Apex Instruments XD-502 - Job Information Screen Overview; Fig. 16 Job Information Screen Overview

XD-502 Digital Console
Apex Instruments, Inc.
34
1
2
3
Fig. 16 Job Information Screen Overview
The Job Information screen allows the user to input general test information that will be added to the
data export spreadsheet.
1. General Sampling Test Information fields
- Client Name
- Plant Name
- Address
- Test Location
- Test Date
- Run Number
- Personnel
- Project Number (three different fields for entry of different sets of project number data)
2. Save Notes button
- Stores the information fields for the export datasheet
3. Additional Notes field
- Allows the user to include additional information to be exported with the sampling datasheet
3.6.11 Job Information screen overview
