CHAPTER 3
UNIT DESCRIPTION
Entire Contents Copyright  2004 by Adaptive Power Systems, Inc. (APSI) • All Rights Reserved • No reproduction without written authorization from APSI.
APS-3000P Series 3 - 5 OM-001-03000-00P-03.9
Voltage Selection
VOLTAGE display
Displays the output voltage / defined voltage value and parameters
during the SYSTEM / PROGRAM set-up.
R indicator
When ON, the display indicates the R-phase output (A-phase in US).
S indicator
When ON, the display indicates the S-phase output (B-phase in US).
T indicator
When ON, the display indicates the T-phase output (C-phase in US).
S indicator
When ON, the display indicates the three-phase output.
PHASE button
Switches between the R / S / T / S phase display.
150 V indicator
When ON, the system is in low-voltage range (0 - 150 VAC).
300 V indicator
When ON, the system is in high-voltage range (0 - 300 VAC).
HIGH / LOW button
Located below the range indicators. Toggles between HIGH and LOW
ranges.
﹀ button
Steps the output voltage down; SYSTEM / PROGRAM parameter select.
︿ button
Steps the output voltage up; SYSTEM / PROGRAM parameter select.
APS-3000P Voltage Display
V O L T A G E
PHASE
R
S
T
S
0-150
0-300
