6 Local Control Panel
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 6-27
Readout of the monitoring
signal memory
If the unit detects an internal fault in the course of internal self-monitoring routines or if it
detects power system conditions that prevent flawless functioning of the unit, then an
entry is made in the monitoring signal memory. A maximum of 30 entries is possible.
After that an ‘overflow’ signal is issued.
Control Step / Description Control
Action
Display
0 Select the entry point for the monitoring
signal memory.
Oper/Rec/MT_RC
Mon. signal record.
1 Press the ‘down’ key to enter the monitoring
signal memory. The oldest entry is displayed.
Mon. signal record.
01.01.97 13:33 SFMON
Checksum error param
2 Press the ‘right’ key repeatedly to display
the entries one after the other in chronological
order. If more than 30 monitoring signals have
been entered since the last reset, the ‘overflow’
signal is displayed as the last entry.
Mon. signal record.
01.01.97 10:01 SFMON
Exception oper. syst.
3 Press the ‘left’ key to display the previous
entry.
Mon. signal record.
01.01.97 13:33 SFMON
Checksum error param
4 If the ‘down’ key is held down while a
monitoring signal is being displayed, the
following additional information will be
displayed:
Mon. signal record.
01.01.97 13:33 SFMON
Checksum error param
First: Time when the signal first occurred
Active: The fault is still being detected
(Yes) or is no longer detected (No)
by the self-monitoring function.
Reset: The fault was no longer detected by
the self-monitoring function and has
been reset (Yes).
Number: The signal occurred x times.
First: 13:33:59.744
Active: Yes
Reset: No
Number: 5
5 Press the ‘up’ key at any point within the
monitoring signal memory to return to the entry
point.
Oper/Rec/MT_RC
Mon. signal record.
To Next Page
