Preparation
• #2 Phillips head screwdriver
Note: Switches come with a template to assist with the rack mounting
Rack Mount
The Table 5: Rack Component Requirements shows the rack components required for each of the
modular switches.
Table 5: Rack Component Requirements
Rack or Cabinet (standard 19" EIA)Switch
Rack Screws
(1)
Rack Nuts
(2)
Notes
DCS-7804 21
(3)
21
(3)
4-post installation
DCS-7808 21
(3)
21
(3)
4-post installation
DCS-7812 27
(3)
27
(3)
4-post installation
DCS-7816 35
(3)
35
(3)
4-post installation
1
The accessory kit includes screws that fit many common equipment racks.
2
Rack nuts are only for racks with unthreaded, rack-post holes.
3
These are in addition to the rack-mount kit screws required for the cradle.
2.3 Unpacking and Moving the Switch
The DCS-7816 accessory kit includes bolts and lifting brackets (Figure 2: Lifting Brackets) that must
be attached to the top of the chassis with the bolts supplied for lifting the chassis from the pallet onto
the transport lift. You can use any appropriate lifting mechanism/tool to unload the switch. A platform lift
is recommended for transportation and installation of the switch. The rack mounting cradle is shipped
nested upside down over the top of the chassis for all switches (Figure 3: Cradle and Switch). There is
a protective film on the top and sides to keep the cradle from scratching the chassis during transport.
