Appendix D
Rear Panel
This appendix displays the rear panel of all switches covered by this guide.
Note: Depending on the components used to populate the chassis, the appearance of a
specific switch could be different.
Figure 36: DCS-7804 Rear Panel (Fully Populated)
1 ESD attachment point 3 Fabric modules 5 Fabric module ejector lever
2 Chassis ground 4 Fabric module screw
