Overview
Fabric Modules DCS-7804R3-FM
DCS-7808R3-FM
DCS-7808R3-FM2
DCS-7812R3-FM
DCS-7816R3-FM
180 W / 248 W
510 W / 778 W
370 W / 518 W
681 W / 917 W
510 W / 778 W
Power Supply (AC) PWR-D1-3041-AC-BLUE 3 W / 10 W
(1)
Power Supply (DC) PWR-D2-3041-DC-BLUE 3 W / 10 W
(1)
7804 Series System Full chassis loaded with:
2 DCS-7800-SUP1A
6 DCS-7804R3-FM
4 DCS-7800R3-48CQ
6 PWR-D1-3041-AC-BLUE
3310 W / 4397 W
7808 Series System Full chassis loaded with:
2 DCS-7800-SUP1A
6 DCS-7808R3-FM
8 DCS-7800R3-48CQ
8 PWR-D1-3041-AC-BLUE
6390 W / 8540 W
7812 Series System Full chassis loaded with:
2 DCS-7816-SUP1A
6 DCS-7812R3-FM
12 DCS-7800R3-48CQ2
10 PWR-D1-3041-AC-BLUE
12490 W / 14788 W
7816 Series System Full chassis loaded with:
2 DCS-7816-SUP1A
12 DCS-7816R3-FM
16 DCS-7800R3-48CQ
24 PWR-D1-3041-AC-BLUE
12881 W / 17150 W
1
With no input power.
Note 1
Includes typical power supply conversion inefficiency. Contact your local Sales Engineer for 7800 power calculator details.
Note 2
Power numbers given as Typical/Maximum or Typical/Hot/Maximum where Hot is defined as 40°C Sea Level.
*
Not N+N redundant power at worst case Temp/Elevation.
