Arjo 2000 - Page 11

11
4 Mount the drain bracket on the right (or left) bottom side
of the panel. (See fig. 6)
5 Cut the drain pipe to a suitable length according to the site
specifications. (See fig. 7 & 8)
Create airgap if needed. (See chapter “Drain installa-
tion” )
Fig. 6
Fig. 7
Fig. 8
