9
12 Move the wooden board to the other side. (See fig. 18)
Repeat the same procedure as in step 11 by mounting of
the second leg. (See fig. 16 & 17)
13 Move the panel forward so the back feet are close to the
end of the pallet. (See fig. 19)
•
14 While one person carefully tips the panel forward have
the second person remove the pallet. (See fig. 20)
Then carefully lower onto all 4 feet and move panel into
position.
15 Refit the bottom frame covers and tighten the screws.
(See fig. 21 and 22).
16 Align the two bottom frame covers with the stabilizer
clip. (See fig. 23)
17 Pull down the roller blind on the front side of the panel
and set into position. (See fig. 24)
WARNING
Moving the panel to the floor requires two
people to keep balance and avoid injury.
Fig. 18
Fig. 19
Fig. 20
Fig. 21
Fig. 22
Fig. 23
Fig. 24
