ARM Cortex-M3 DesignStart User Manual

2.2 Running the self-test program
The MPS2+ FPGA platform uses a self-test program to test its main components. This self-test program
is specific to the prebuilt image, which is based on the Cortex-M3 DesignStart Eval example system.
If you extend the example system, then you may need to modify the self-test program.
If you need to modify and recompile the self-test image, you are required to install legacy support in
Keil
®
MDK. This provides the low-level interface which is used by the self-test. Source code for the self-
test is located at m3designstart/selftest/Build_Keil/ in the deliverables.
To run a self-test program, follow these steps:
1. Connect an RS232 serial lead to the General UART connector (FPGA), on the MPS2+ platform.
2. Configure the UART according to the following settings:
Table 2-1 UART configuration
Configuration Value
Baud rate 38 400
Data bits 8
Stop bits 1
Parity None
Flow control XON/XOFF protocol
3. Select the self-test program that you want to run based on the following options available that are
displayed by the UART console window when the MPS2+ platform has booted up:
Versatile Express Cortex-M Prototyping System (V2M-MPS2) Test Suite
Version 1.0.0 Build date: Mar 8 2017
Copyright (C) ARM Ltd 2015. All rights reserved.
V2M-MPS2 revison C
Application Note AN511, FPGA build 1
CPU: Cortex-M3 r2p1
Summary of results
====================================
1 AACI (Audio) : Not Run
2 CLCD (Video) : Not Run
3 TSC (touchscreen) : Not Run
4 LEDs/Switches/Buttons : Not Run
5 SSP (eeprom) : Not Run
6 Ethernet : Not Run
7 Memory : Not Run
8 Timer : Not Run
9 RTC : Not Run
Select the test you wish to run. (X - Exit)
Choice:
Note
To run Test 1, AACI (Audio), you must connect a 3.5mm stereo jack lead from the audio output
connector to the audio input connector.
When the test runs, the console window displays the self-test status:
Versatile Express Cortex-M Prototyping System (V2M-MPS2) Test Suite
Version 1.0.0 Build date: Mar 8 2017
Copyright (C) ARM Ltd 2015. All rights reserved.
V2M-MPS2 revison C
2 Using the prebuilt FPGA image
2.2 Running the self-test program
ARM 100896_0000_00_en Copyright © 2017 ARM Limited or its affiliates. All rights reserved. 2-21
Non-Confidential
