Technical data
10 182099015-V01-10.Juni2013-GA-MCL31-THAI
Classification according to
directive 93/42/EEC
II b
Accessories
See chapter 7 Accessories
Operating mode
The device has been designed for continuous operation
Smoke evacuation
Inbuilt smoke evacuation with three-stage filter system
Specification
Laser
Laser model
Er:YAG laser (solid state laser)
Wavelength
2940 nm
Laser class
4
Required laser safety goggles
(As specified in DIN EN 207: 2009)
2940 nm I LB4
Pulse duration
100/300/600/1000 µs (Ablation mode)
600 µs (Thermal mode)
Pulse energy
max. 2.5J
Pulse frequency
1/4/8/10/12/15/20 Hz (Ablation mode)
20 Hz (Thermal mode)
Spot sizes (handpieces)
VarioTEAM handpiece: 1/2/3/4/5/6 mm
VarioTEAM XL handpiece: 8/10/12 mm
MicroSpot Zoom handpiece: 13 ×13 mm
169 spots, diameter 350 - 600 µm
10 – 25% coverage
Output power tolerance
± 10%
Laser beam mode
Multimode
Laser beam diameter at the
handpiece output
See spot sizes
Ablation mode: 2 – 250 J/cm
2
Energy density
Thermal mode: 1.5 J/cm
2
MicroSpot mode: 2 – 75 J/cm
2
(max. sequence of 15
pulses)
Beam divergence at the handpiece
output (round angle, 1/e
2
)
Max. 80 mrad (4.5°)
Nominal ocular hazard distance
(with handpiece)
2 m
