Asclepion MCL 31 Dermablate - Installation; Device design

Start-up
182099015-V01-10.Juni2013-GA-MCL31-THAI 17
4.2 Installation
4.2.1 Device design
Articulated arm
Handpiece connector
Smoke evacuator inside
Connector for suction hoses
Handpiece connector
Speed control for smoke
evacuator (retractable)
Display with
touchscreen
Laser emergency
STOP switch
Key switch
Filter package for smoke
evacuator behind cover
Handpiece connector
Connector for suction hoses
Speed control for smoke
evacuator (retractable)
Figure 5: Connections on the front panel of the device
