5. Handset Configuration
Configuring Handset for All Location Data
If a network of both DECT and LF devices are deployed together, the handset can be
configured to show data from both devices as shown in figure 5:
Figure 5. All Location Data
To configure the handset to provide both DECT and LF location data simultaneously, perform
the following procedure:
1 Press the "Menu" soft key.
2 Select "Calls".
3 Select "Admin menu".
NOTE: The "Admin menu" is only visible if the Admin menu is activated. To activate
the Admin menu, see
6.1.1 Activating the Admin Menu on page 62
4 From the Admin menu, select "Location info".
5 Select "All Location info". Location information from both DECT and LF devices is
displayed in the handset display as shown in
figure 5.
A handset configured to display both DECT location data and LF location data shows the
following:
• L1- L4: The four last valid location IDs. For DECT location devices, the location ID with
highest difference between the measured signal strength and threshold value is
regarded as the current location (L1). For LF location devices, the last received location ID
is regarded as the current location (L1). If the handset receives current locations from
both DECT location devices and LF location devices, the last received location is regarded
as the current location (L1).
Note: No additional information is given whether the locations IDs are received from a DECT
location device or LF location device.
DECT and LF Location Indications
When the DECT Location info, LF Location info or All Location info screens are setup, the
handset can be configured to provide additional indications to the support engineer as the
handset is carried into a valid location. A beep indication, a LED indication, or both can be
activated to indicate when valid locations are received. The activation parameters that can
be configured via the PDM/Device Manager are as follows:
Location > Indicate location with beep
• Off - The beep indication is turned off
• Beep on new - The handset beeps when it receives a new valid location. A location is
considered as "new" when the location ID is changed for the current location.
• Beep always - The handset beeps when it is receives a valid location.
12:34
Back
All Location info
L1: 0555, t1: 02118 s
L2: 0666, t2: 02115 s
L3: 0444, t3: 02168 s
L4: 0333, t4: 02103 s
