6.1 POWER TURN-ON PROCEDURE, cont.
The display will sequence to the SUMMARY DISPLAY indicating the system’s operational state.
Both input and Converter output power should indicate OFFLINE at this time. Return to this screen
at any time by pressing the SYSTEM STATUS (7) button.
At this time both of the red LED indicators next to the OFF buttons (3 & 4) should be illuminated.
Press the SHORE POWER (5) display button. The display will indicate basic shore power
information; voltage, current, kVA, and frequency. Verify the displayed voltage indicates the
expected voltage and frequency. If not, do not proceed until contacting factory personnel.
Additional SHORE POWER information can be obtained by pressing the F2 (9) button: wattage and
input power factor can now be viewed. Return to the primary screen by pressing the F1 (8) button.
Press the CONVERTER POWER (6) button and the screen will now change. Output voltage(s) and
current(s) should indicate zero.
SUMMARY DISPLAY AC12 LOAD:XXX.X %
INPUT#1:OFFLINE STATUS: OK
SYS:XXXXXXXXXXXXXXXX CONVERTER: OFFLINE
AUTO-RESTART: OFF XX:XX:XX
SHORE POWER INPUT 50.1Hz
VOLTAGE: 221 V
CURRENT: 1 A
LOAD: 0.2 kVA
CONVERTER OUTPUT#1 OUTPUT#2 60.0Hz
VOLTAGE: 0 V O V
CURRENT: 0 A 0 A
LOAD: 0.0 kVA 0.0 kVA
To Next Page
