AC08 and AC12 Operations Manual....
23
6.1 POWER TURN-ON PROCEDURE, cont.
To start the system, press the SHORE POWER - ON (1) button. The system will begin a soft-start
procedure which requires approximately 2 seconds to complete. At the conclusion of this process
the indicator LED in the SHORE POWER control area of the display should change from red to
green. View the display information for CONVERTER POWER (6) and verify the displayed
voltage is at the desired potential, frequency, and form.
NOTE: It is normal under no load conditions for the currents to indicate 2-4 Amps flowing. This
level of current is due to the internal filters and will not degrade the system’s power rating.
When ready to transfer the yacht’s load to the converter, press the CONVERTER POWER ON (2)
button on the control panel. This will place voltage at the output terminals of the converter. The
green ON indicator LED should now be lighted. The yacht’s load may be transferred to the
converter at this time.
When load has been transferred to the converter, monitor the load currents and voltages. Ensure the
load is within the system ratings. Monitor the shore power voltage and current levels with load
applied. Refer to published rating curves for maximum current, kVA, and kW levels.
CONVERTER OUTPUT#1 OUTPUT#2 60.0Hz
VOLTAGE: 120 V 120 V
CURRENT: 2 A 2 A
LOAD: 0.2 kVA 0.2 kVA
