Press the Left arrow key () to move to the next option.
IP> C6 Time = 01.0
Range 0-99.9S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IP> C6 Time (OC Definite Time
Delay) can be selected.
The setting range for definite time is from inst. (00.0) to
99.9secs in steps of 0.1secs. This setting is effective only when
C6 curve is selected for phase.
Press the Left arrow key () to move to the next option.
IE> C6 Time = 01.0
Range 0-99.9S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IE> C6 Time (EF Definite Time
Delay) can be selected.
The setting range for definite time is from inst. (00.0) to
99.9secs in steps of 0.1secs. This setting is effective only when
C6 curve is selected for EF.
Press the Left arrow key () to move to the next option.
IP>> Delay = 00.10
Range 0 – 10.00S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IP>> Delay (HF Operating Delay)
for Phase can be selected.
The setting Range for Phase HF operating time is from inst. (0)
to 10.00 secs in steps of 00.01 secs.
Press the Left arrow key () to move to the next option.
IE>> Delay = 00.10
Range 0 – 10.00S
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired IE>> Delay (HF Operating Delay)
for EF can be selected.
The setting Range for EF HF operating time is from inst (0) to
10.00 secs in steps of 00.01 secs.
Press the Left arrow key () to move to the next option.
