Trip Ckt = 02
01= Yes, 02 = No
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired Test Ckt. functions can be enable
or disable, i.e. 1 or 2.
Press the Left arrow key () to move to the next option.
Ann Type = 001
Range 1 – 4
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired ANN. Type can be set. The
setting Range is 1 to 4.
ANN –
Type 1
ANN –
Type 2
ANN –
Type 3
ANN –
Type 4
RELAY 1
OC1 OC – HF HF COM ALARM
RELAY 2
OC2 OC – IDMT IDMT PROTH.
RELAY 3
OC3 EF – HF PHASE PHASE
RELAY 4
EF EF – IDMT EF EF
Press the Left arrow key () to move to the next option.
Ann Cont. = 001
SR = 1 HR = 2
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired Annunciation Contact can be
set, i.e. 1 or 2. In which, 1 corresponds with SR (Self-Reset)
and 2 correspond with HR (Hand-Reset) respectively.
Press the Left arrow key () to move to the next option.
Trip Cont. = 001
SR = 1 HR = 2
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired Trip Cont. can be set, i.e. 1 or 2.
In which, 1 corresponds with SR (Self-Reset) and 2 correspond
with HR (Hand-Reset) respectively.
Press the Left arrow key () to move to the next option.
BF Cont. = 001
SR = 1 HR = 2
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired BF Cont. can be set, i.e. 1 or 2. In
which, 1 corresponds with SR (Self-Reset) and 2 correspond
