ADR141A /
Doc ID: ADR241A _IM_01
Ref ID: ADR241A /IM/PC-SI
Rev No. : 02
Page No. : 50 of 150
12
Private settings This is used to view the current value and the expected value
13
Control Operation This is used to operate, relay control operation through PC
14
General/Analog This used to view Relay name, Version, and compatibility.
NOTE: The above features are generally provided with all the ASHIDA Relays but the * marked
features are not applicable to this product
3.2.1 Parameter Display
Online Parameters along with their values & Display Mode units are displayed and refreshed
on successful communication.
Figure 6: Parameter Display
3.2.2 IEDs Din Display
These are IED Din s; these IEDs along with their online status are display.
Figure 7: Auxiliary Status
