Ashida ADR141A - Page 84

Doc ID : ADR241A_IM_01
Ref ID : ADR241A/IM/CS
Rev No. : 02
Page No. : 84 of 150
ADR141A /
ADR241A
Sr. No.
Function
Code
Register
No. of
Regs
Format
Reg.
Type
Address
Map
1 Product
Information
03
Manufacturer
Name
10 20-Bytes
ASCII
R 4x00001 –
4x00010
Relay Name 10 20-Bytes
ASCII
R 4x00011 –
4x00020
Model 10 20-Bytes
ASCII
R 4x00021 –
4x00030
Version 10 20-Bytes
ASCII
R 4x00031 –
4x00040
Relay
Description
10 20-Bytes
ASCII
R 4x00075 –
4x00084
Sr. No.
Function
Code
Register
No. of
Regs
Format
Reg.
Type
Address
Map
2 Relay
Configuration
03
Num Status (s) 1 16 bit R 4x00258
Num Controls (c) 1 16 bit R 4x00259
Num Parameters
(p)
1 16 bit R 4x00260
Num Faults (f) 1 16 bit R 4x00261
Sr. No.
Function
Code
Register
No. of
Regs
Format
Reg.
Type
Address
Map
3 Time
Synchronization
(Unicast/Broadcast)
03/16
Year 1 16 bit R/W 4x02049
Month- Day 1 16 bit R/W 4x02050
Hour, Min 1 16 bit R/W 4x02051
Milliseconds 1 16 bit R/W 4x02052
