Ashida ADR141A - Page 85

Doc ID : ADR241A_IM_01
Ref ID : ADR241A/IM/CS
Rev No. : 02
Page No. : 85 of 150
ADR141A /
ADR241A
Sr.
No.
Function
Code
Register
No. of
Regs
Format
Reg.
Type
Address
Map
4 Status and Logical
Status
02
Auxiliary input 1 1 1 bit R 1x32769
Auxiliary input 2 1 1 bit R 1x32770
Auxiliary input 3 1 1 bit R 1x32771
Auxiliary input 4 1 1 bit R 1x32772
General pick-
up
1 1 bit R 1x32773
Start/Pick-up
L1
1 1 bit R 1x32774
Start/Pick-up
L2
1 1 bit R 1x32775
Start/Pick-up
L3
1 1 bit R 1x32776
General Trip 1 1 bit R 1x32777
Trip L1 1 1 bit R 1x32778
Trip L2 1 1 bit R 1x32779
Trip L3 1 1 bit R 1x32780
Trip Ip> 1 1 bit R 1x32781
Trip Ip>> 1 1 bit R 1x32782
Test 1 1 bit R 1x32783
Breaker Failure 1 1 bit R 1x32784
Ie> Pickup 1 1 bit R 1x32785
Ie>> Pickup 1 1 bit R 1x32786
Trip Ie> 1 1 bit R 1x32787
Trip Ie>> 1 1 bit R 1x32788
CLP 1 1 bit R 1x32789
Protection
active
1 1 bit R 1x32790
Relay Error 1 1 bit R 1x32791
LED reset 1 1 bit R 1x32792
Local para
settings
1 1 bit R 1x32793
Trip Ckt 1 1 bit R 1x32794
Ip> PKP 1 1 bit R 1x32795
Ip>> PKP 1 1 bit R 1x32796
