Setting Up

Application Examples

ENC 1201 Version 1.0 Page 14

UsingtheENC1201asStageboxandSplitterforLiveEvents

In the following example, the ENC 1201 is used as stagebox and splitter for a live perfor-

mance. It transmits the 8 microphone signals both to the FOH console and to the monitor

mixer:

MIC IN 1~8

1 2 3 4 5 6 7 8

ENC 1201

1 2 3 4

Drum Microphones, etc.

FOH Console

Monitor Mixer

Switch

Dante RX

Dante TX
