Conguring the Unit via its Web Interface
Receivers (Inputs)
ENC 1201 Version 1.0 Page 32
Reference
This fader icon allows you to set the analog reference level for 0dBFS (digital full-scale
level, i.e. the highest digital level before clipping occurs). Depending on the console(s)
used and on the requirements of the organization or client one is working for, this refer-
ence may have to be +15dBu= 0dBFS, +24dBu= 0dBFS, or something else. This setting
aects the read-out of the Peak Level meter below this fader.
One of the advantages of the ENC 1201 is that it provides four splits per microphone
input, allowing you to simultaneously cater to the requirements of devices with dierent
headrooms.
The setting range for this parameter is –15dBu~+24dBu. Hold down the Shift key while
double-clicking the fader to reset the fader to 0dBu. Double-click the fader to set it to the
minimum value.
PeakLevel
The “Peak Level” meter shows the peak level of the associated microphone signal.
The audio signal’s current level is displayed in orange on a scale between –∞dBFS (corre-
sponds to –91dBFS) and 0dBFS.
