Conguring the Unit via its Web Interface
Receivers (Inputs)
ENC 1201 Version 1.0 Page 33
EQ
The ENC 1201 is equipped with 3-band parametric equalizers and low-cut (or
high-pass) lters.
LowCut
The “Low Cut” section allows you to set the low-cut (high-pass) lter. There are
two parameters:
1. Use the drop-down menu (t) to set the lter slope. The following settings
can be selected: O (Low Cut o), 12dB/octave, 18dB/octave, 24dB/octave,
36dB/octave.
2. The cuto frequency (Freq) can be set with the knob icon: click it and
hold down the mouse button to select the desired frequency (20Hz~20kHz).
You can also set the frequency by clicking and dragging the gray area in the
curve section.
Parametric EQ: Band1~Band3
Each band has 3 knob icons, some of which are not available for certain lter
types (and are therefore grayed out).
You can also set the frequency of these bands by clicking and dragging the
gray area in the curve section. To change the gain setting, drag the gray bar up
or down.
