3-14
Chapter 3: Motherboard Information
7. Power connector (PWR1)
Connects to the power sharing board and supplies power to the motherboard.
• Use of a PSU with a higher power output is recommended when configuring a system
with more power-consuming devices. The system may become unstable or may not
boot up if the power is inadequate.
• Ensure that your power supply unit (PSU) can provide at least the minimum power
required by your system.
