Chapter 1: Product Introduction
1-8
• * This port is for ASUS ASMB9-iKVM only.
• The Q-Code LED provides the most probable cause of an error code as a starting
point for troubleshooting. The actual cause may vary from case to case.
• Refer to the Q-Code table for details.
Redundant power supply
Power connector
VGA port
Mgmt LAN port*
Gigabit LAN port 2
Q-Code LED
USB 3.1 Gen 1 ports
Power button
Gigabit LAN port 1
Expansion card back plate
RS720-E9-RS8 (with rear bay model)
2 x 2.5” Drive Bays
• * This port is for ASUS ASMB9-iKVM only.
• The Q-Code LED provides the most probable cause of an error code as a starting
point for troubleshooting. The actual cause may vary from case to case.
• Refer to the Q-Code table for details.
Redundant power supply
Power connector
VGA port
Mgmt LAN port*
Gigabit LAN port 2
Q-Code LED
USB 3.1 Gen 1 ports
Power button
Gigabit LAN port 1
RS720-E9-RS8-G
Expansion card back plate
Expansion card slot
OCP Mezzanine slot
Expansion card slot
OCP Mezzanine slot
