2-23
ASUS RS720-E9-RS8/RS8-G
2.5.3 Installing an expansion card to riser card bracket 3
(for RS720-E9-RS8 only)
Toinstallanexpansioncardtotherisercardbracket3:
2. Firmly hold the riser card bracket 3, then pull it up to detach it from the PCIE4 slot on
the motherboard.
1. Remove the two screws that
secure the riser card bracket 3 to
the chassis.
Riser card bracket 3
3. Remove the screw from the
metal cover (A), then remove the
metal cover (B) from the riser
card bracket 3.
Metal cover
