2.3.2 Memory Configurations
Youmayinstall4GB,8GB,16GB,and32GBRDIMMs;32GB,and64GBLRDIMMs;and
64GBand128GBLRDIMMs(3DS)intotheDIMMsocketsusingthememorycongurations
in this section.
• RefertoASUSServerAVLfortheupdatedlistofcompatibleDIMMs.
• AlwaysinstallDIMMswiththesameCASlatency.Foroptimumcompatibility,itis
recommended that you obtain memory modules from the same vendor.
1 CPU Configuration (must be on CPU1)
DIMM_A2 DIMM_A1 DIMM_B2 DIMM_B1 DIMM_C2 DIMM_C1
1 DIMM
•
2 DIMMs
•
4 DIMMs
• •
6 DIMMs
• • •
8 DIMMs
• • • •
12 DIMMs
• • • • • •
1 CPU Configuration (must be on CPU1)
DIMM_D2 DIMM_D1 DIMM_E2 DIMM_E1 DIMM_F2 DIMM_F1
1 DIMM
2 DIMMs
•
4 DIMMs
• •
6 DIMMs
• • •
8 DIMMs
• • • •
12 DIMMs
• • • • • •
2 CPU Configuration
DIMM_A2 DIMM_A1 DIMM_B2 DIMM_B1 DIMM_C2 DIMM_C1
2 DIMMs
•
4 DIMMs
•
8 DIMMs
• •
12 DIMMs
• • •
16 DIMMs
• • • •
20 DIMMs
• • • • •
24 DIMMs
• • • • • •
