3-3

ASUS RS720-E9-RS8/RS8-G

3.2 Installing the tool-less rack rail

To install the tool-less rack rails into the rack:

1. Securethetwoxinglatchestothetwosidesoftheserverusingthesetoflatch

screws.

The locations of the screw holes vary with different server models. Refer to your server

user manual for details.

For 1U devices

For 2U devices

Front end

of system

Front end

of system
