2-51
ASUS RS720-E9-RS8/RS8-G
1
2
3 4
1
2
3 4
2.7 SATA/SAS backplane cabling
RS720-E9-RS8 (without rear bay model)
Connects the data cable
connected to the motherboard
Connects the data cable connected to
the ASUS PCIE-NVME4-OCuLink card
Connects a 8-pin plug
from motherboard
PWR1
MSAS_HD1
OCUPCIE1
OCUPCIE3
OCUPCIE4
OCUPCIE2
MSAS_HD2
Connects the data cable
connected to the motherboard
