2-55
ASUS RS720-E9-RS8/RS8-G
2.8.2 Redundant power supply module
To replace a failed redundant power supply module:
1. Lift up the power supply module lever.
2. Hold the power supply module lever and
press the PSU latch.
3. Pull the power supply module out of the
system chassis.
4. Insert the replacement power supply
module into the chassis, then push it
inwards until the latch locks into place.
Module lever
PSU latch
