Asus RS720-E9-RS8 User Manual

Chapter 3: Installation Options
3-4
A 1U space consists of three square mounting holes with two thin lips on the top and the
bottom.
Followsteps2to4ifthedepthofyourserverrackexceeds850mm,ifthedepthofyour
serverrackislessthan850mm,pleaseskipsteps2to4andproceedwithstep5.
1U
Rail component
3. Align the rail component with the right rack rail and secure it using four (4) bundled
screws.
4. Follow steps 2 and 3 to secure the rail component to the left rail rack.
5. Selectadesiredspaceandplacetheappropriaterackrail(leftandright)onopposite
positions on the rack.
2. Slightlyslideoutandextendtherightrackrail,thenprepareoneofthebundledrail
components.
