2 CPU Configuration
DIMM_D2 DIMM_D1 DIMM_E2 DIMM_E1 DIMM_F2 DIMM_F1
2 DIMMs
4 DIMMs
•
8 DIMMs
• •
12 DIMMs
• • •
16 DIMMs
• • • •
20 DIMMs
• • • • •
24 DIMMs
• • • • • •
2 CPU Configuration
DIMM_G2 DIMM_G1 DIMM_H2 DIMM_H1 DIMM_J2 DIMM_J1
2 DIMMs
•
4 DIMMs
•
8 DIMMs
• •
12 DIMMs
• • •
16 DIMMs
• • • •
20 DIMMs
• • • • •
24 DIMMs
• • • • • •
2 CPU Configuration
DIMM_K2 DIMM_K1 DIMM_L2 DIMM_L1 DIMM_M2 DIMM_M1
2 DIMMs
4 DIMMs
•
8 DIMMs
• •
12 DIMMs
• • •
16 DIMMs
• • • •
20 DIMMs
• • • • •
24 DIMMs
• • • • • •
