POSI-TRACK 2800 & 2810
PAGE 24
ASV, INC.
BI-DIRECTIONAL OPERATION
A unique feature of the POSI-TRACK is the
ability to reverse the seat and the footrest in or-
der to face the engine.
1. Remove the footrest by pulling up from both
ends with even pressure. (Fig. 25)
2. To remove the seat, remove the two lynch
pins, which secure the seat to the pegs, and un-
plug the seat cord from the console. Pull up on
the seat from both sides. (Fig. 26)
3. Once removed, take the seat out of the cab.
Place the footrest over the pegs where the seat
used to be. Place the seat on the pegs where the
footrest used to be. (Fig. 27)
4. The seat cord must be plugged into the recep-
tacle on the console in order for the vehicle to
operate. There is a receptacle on both consoles
so the seat can be plugged in no matter which di-
rection it is facing. (Fig. 28)
NOTE
When operating the POSI-TRACK as a tractor,
with the loader removed and with the seat fac-
ing the engine, the side screens should be re-
moved to allow better access to the operator's
seat.
NOTE
When the seat is facing the engine, the en-
closed cab is not functional. The door will not
close and there is poor access to the operator’s
compartment.
Fig. 25
Fig. 26
Fig. 27
Fig. 28
GENERAL OPERATION
