POSI-TRACK 2800 & 2810
PAGE 7
ASV, INC.
POSITIVE DRIVE
Self-Cleaning Internal Drive Sprocket drives the track via two rows of molded rubber drive lugs
on interior of track. 24 roller pins per sprocket, 110 molded drive lugs per track.
UNDERCARRIAGE
Type
Number of wheels supporting the track
Lubrication
TRANSMISSION & FINAL DRIVE
Drive Pumps
Drive Motors
Final Drive
AUXILIARY PUMPS
Low Flow at full engine rpm
High Flow at full engine rpm
Pressure at full flow
CAPACITIES
Fuel Tank
Hydraulic Reservoir
Coolant
Engine Oil w/filter
P
Articulating roller carriages with rubber tor-
sion axles
48
Sealed, oil bath bearings
P
Sundstrand, tandem variable displacement
Eaton Model , 2.48 cu. In.
Planetary gear box
P
19 gallons per minute max.
25 gallons per minute max.
2,750 psi
P
13 gal.
28 gal.
2.3 gal.
6.8 qt.
SPECIFICATIONS
