POSI-TRACK 2800 & 2810
PAGE 22
ASV, INC.
The operating capacity refers to how much addi-
tional weight can be put into the POSI-TRACK’s
loader bucket. This operating capacity is meas-
ured at the mid point of the low profile bucket.
The operating capacity is 2,350 lbs. when the low
profile bucket is quick attached to the machines
loader assembly, and is at the farthest point from
the vehicle (half way up). The heavier the
attachment, such as a 4-in-1 bucket, the less the
operating capacity will be. Moving the load
farther from the vehicle, such as a tree spade, will
significantly reduce the operating capacity.
THE MOST SIGNIFICANT FACTOR IN OPERATING CAPACITY IS THE
DISTANCE BETWEEN THE FRONT PIVOT POINT OF THE VEHICLE
AND THE CENTER OF GRAVITY OF THE MATERIAL BEING CARRIED.
GENERAL OPERATION
2,350 LB. OPERATING
CAPACITY RATED AT
BUCKET’S CENTER OF
GRAVITY
FRONT PIVOT POINT
INCREASING THE DISTANCE FROM
THE FRONT PIVOT POINT TO THE
PAYLOAD WILL DECREASE THE
OPERATING CAPACITY
