ASV 2810 Service Manual

POSI-TRACK 2800 & 2810
PAGE 30
ASV, INC.
GREASE POINTS
LOADER ASSEMBLY
There are 12 grease fittings on the POSI-
TRACK’S loader assembly, which should be
greased every 25 hours, or as needed. The
grease fittings are located in the following
spots on both sides of the loader:
1. The main loader hinge points. (Fig. 35)
2. Both ends of the lift cylinders. (Fig. 36, 37)
3. Both ends of the quick-attach cylinders.
(Fig. 38, 39)
4. Hinge points for the quick-attach. (Fig. 40)
GENERAL MAINTENANCE
Fig. 36
Fig. 37
Fig. 38
Fig. 39
Fig. 40
Fig. 35
