POSI-TRACK 2800 & 2810
PAGE 20
ASV, INC.
FRAME MOUNT
Frame mount attachments include the six-way
dozer blade, three-point hitch, and the frame
mount backhoe. The frame mount receptacle
allows the attachment to be rigidly mounted to
the frame for added strength and stability. The
following instructions are for the six-way dozer
blade.
1. If the vehicle has a loader assembly installed,
use the loader lockout pins to secure the loader
in the “up” position. (See page 18)
2. Turn the engine off and then turn the key to
the “on” position to unlock the loader valve.
(DO NOT RESTART THE ENGINE) Move
the loader control and the auxiliary valve in all
directions to relieve any pressure in the lines.
3. Disconnect all loader hoses at the quick-
couplers.
4. Using a floor jack, raise the dozer mount so
it is high enough to line up with the vehicle
frame mount receptacle. (Fig. 19)
5. Remove the loader stop (A) by removing the
two pins (B).
6. Drive the vehicle so the dozer mount (C) and
the axle arms (D) slide into the receptacle (E)
and around the front axle.
Fig. 19
A
B
C
D
E
GENERAL OPERATION
