7
Getting started
IMPORTANT INFORMATION
1. Use only the power adapters supplied with this product or equivalent. To order a replacement
power adapter, visit our website at www.telephones.att.com, or call
1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.
2. These power adapters are intended to be correctly oriented in a vertical or floor mount position.
The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-
table or cabinet outlet.
Telephone base installation (1-line jack)
If you subscribe to high-speed Internet service (Digital Subscriber Line - DSL)
through your telephone lines, you must install a DSL filter between the
telephone base and the telephone wall jack. The filter will prevent noise
and caller ID problems caused by DSL interference. Please contact your DSL
service provider for more information about DSL filters.
The telephone line cord can be plugged into either LINE 1/L1+L2 or LINE 2
telephone jack. However, you have to plug the telephone line cord into
LINE 2 jack if you need to connect to a fax machine or modem through DATA
port. All data will only be transmitted through LINE 2 jack.
If you have 1-line wall jack, install the telephone base as shown below.
Telephone base installation
1. Plug the small end
of the telephone
base power adapter
into the power jack
at the bottom of the
telephone base.
2. Plug the telephone
base power adapter
into an electrical
outlet not controlled
by a wall switch.
3. Plug one end of the
telephone line cord into the
LINE 1/L1+L2 or LINE 2
telephone jack at the bottom
of the telephone base.
4. Plug the other end
of the telephone
line cord into a
telephone jack.
5. Plug the other
end of the coiled
handset cord into
the jack at the
bottom of the
telephone base
and route the cord
through the slots.
Telephone
line cord
DSL filter (not included,
required for DSL users).
