ATEN CS1732B User Manual

4. Keyboard Port Operation
21
Going Directly to a Port
Note: The n stands for the computer’s Port ID number (1, 2, 3, 4). Replace the
n with the appropriate Port ID when entering hotkey combinations.
Hotkey Action
[Num Lock] + [-]
[Enter]
Brings the KVM, USB hub, and audio focus from the port that currently
has the KVM focus to the next port on the installation (1 to 2; 2 to 1 for
the CS1732B; 1 to 2; 2 to 3; 3 to 4; 4 to 1 for the CS1734B).
Note: The KVM, USB hub, and audio focus all go to this port even if
they were on different ports to begin with.
[Num Lock] + [-] [K]
[Enter]
Brings only the KVM focus from the port that currently has it to the next
port on the installation. The USB hub and audio focus remain where
they are.
[Num Lock] + [-] [U]
[Enter]
Brings only the USB hub focus from the port that currently has it to the
next port on the installation. The KVM and audio focus remain where
they are.
[Num Lock] + [-] [S]
[Enter]
Brings only the audio focus from the port that currently has it to the next
port on the installation. The KVM and USB hub focus remain where they
are.
[Num Lock] + [-] [n]
[Enter]
Brings the KVM, USB hub, and the audio focus to the computer
attached to the port corresponding to the specified Port ID.
Note: The KVM, USB hub, and audio focus all go to this port even if
they were on different ports to begin with.
[Num Lock] + [-] [n] [K]
[Enter]
Brings only the KVM focus to the computer attached to the specified
port. The USB hub and audio focus remain where they are.
[Num Lock] + [-] [n]
[U] [Enter]
Brings only the USB hub focus to the computer attached to the
specified port. The KVM and audio focus remain where they are.
[Num Lock] + [-] [n] [S]
[Enter]
Brings only the audio focus to the computer attached to the specified
port. The KVM and USB hub focus remain where they are.
[Num Lock] + [-] [n] [K]
[U] [Enter]
Brings the KVM and USB hub focus to the computer attached to the
specified port. The audio focus remains where it is.
[Num Lock] + [-] [n] [K]
[S] [Enter]
Brings the KVM and audio focus to the computer attached to the
specified port. The USB hub focus remains where it is.
[Num Lock] + [-] [n]
[U] [S] [Enter]
Brings the USB hub and audio focus to the computer attached to the
specified port. The KVM focus remains where it is.
[Num Lock] + [-] [n] [K]
[S] [U] [Enter]
Brings the KVM, USB hub, and the audio focus to the computer
attached to the port corresponding to the specified Port ID.
Note: This is the same action as [Num Lock] + [-] [n] [Enter]
