37
Chapter 7
The Firmware Upgrade Utility
The Windows-based Firmware Upgrade Utility (FWUpgrade.exe) provides a
smooth, automated process for upgrading the KVM switch’s firmware.
The Utility comes as part of a Firmware Upgrade Package that is specific for
each device. New firmware upgrade packages are posted on our web site as
new firmware revisions become available.
http://www.aten.com
Before you Begin
1. From a computer that is not part of the KVM installation go to our Internet
support site and choose the model name of your device (CS1732
B /
CS1734
B) to get a list of available Firmware Upgrade Packages.
2. Choose the Firmware Upgrade Package you want to install (usually the
most recent), and download it to your computer.
3. Use the Firmware Upgrade Cable provided to connect a COM port on
your computer to the Firmware Upgrade Port of your switch.
4. Shut down the computers on your CS1732
B / CS1734B installation.
5. Invoke Firmware Upgrade Mode (see FIRMWARE UPGRADE, page 33).
The front panel LEDs flash together to indicate Firmware Upgrade Mode
is in effect.
USB 2.0
CPU 4
CPU 1
CPU 2
CPU 3
