Chapter 2
Hardware Setup
Cable Connection
To set up your CS1732B / CS1734B installation, refer to the installation
diagram on the following pages, and do the following:
1. Plug your USB keyboard and USB mouse into the USB Ports located on
the unit's back panel.
2. Plug your monitor into the Console monitor port located on the unit's rear
panel and power on the monitor.
Note: Two stickers showing OSD/Hotkey combinations, one for the
keyboard and one for the Console monitor, have been provided with
the CS1732
B / CS1734B package. See OSD / Hotkey Stickers,
page 25 for details.
3. Plug your main microphone and speakers into the Console microphone
and 2.1 surround sound speaker jacks located on the unit's front panel. The
microphone and speakers plugged into this panel have priority over those
plugged into the back panel.
4. Using a KVM cable set (provided with this package), plug the custom
SPHD connector into any available KVM Port on the switch and plug the
accompanying microphone and speaker connectors into the KVM Port's
microphone and speaker jacks.
Note: 1. The connectors and jacks are color coded and marked with an
appropriate icon for easy installation.
2. Be sure that all the plugs are in the same KVM Port sockets (all
in Port 1, all in Port 2, etc.).
1. Important safety information regarding the placement of this
device is provided on page 41. Please review it before proceeding.
2. Make sure that the power to all devices connected to the
installation are turned off. You must unplug the power cords of
any computers that have the Keyboard Power On function
